1.54 inch 240x240 IPS TFT LCD Display with MicroSD Card Breakout

DFRobot 1.54” IPS TFT LCD Display with MicroSD Card Breakout Introduction This display module features high resolution, low power consumption, wide angle and easy-to-connect. With a small size of 1.54”, it offers 240x240 resolution. Note: MicroSD Card is not included. Features Wide Angle of View High Resolution GDI Interface: plug and play Onboard MicroSD card slot Applications Wearable devices MP3/MP4 Weather Display Specification Operating Voltage: 3.3V~5V IPS Angle of View: 80/80/80/80 Color Depth: 16-bit (RGB565) Pixels: 240 × 240 Connection Port: SPI Driver Chip: ST7789 Brightness: 250 (Typ) cd/m2 Full-screen Power Consumption: about 17mA?3.3V) 17mA?5V??Typ? Operating Temperature: -30?~+70? Display Area: 27.72×27.72 mm Mount Hole Diameter: 2mm Weight: 19g Shipping List 1.54”240x240 IPS TFT LCD Display with MicroSD Card Breakout x1 2.54-10P Single-row Black Pin x1 FPC0.5-18PIN Flex Flat Cable Reverse Direction 10cm x1
