Specification:
- DC Voltage:600mV/6V/60V/600V(+/-0.5% +2)
- AC Voltage:6V/60V/600V(+/-1.0%+3)
- DC Current:60A/400A (+/-2.5% +10 )
- AC Current:60A/400A (+/-2.5% +10 )
- Resistance: 600/6K/60K/600K/6M/60M ohm(+/-1.5% +3 )
- Capacitance: 9.999nF/99.99nF/999.9nF/9.999µF (+/-3.0% +10)
- 99.99µF(+/- 5% + 10 )
- 999.9µF/9.999mF/99.99mF(+/-10% +20 )
- Temperature:-20?~1000? /-4?-1832?(+/-3%)
- Frequency:9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz(+/-0.1%+5 digits)
- Duty Cycle: 0.1%~99.9%
Why choose INFURIDER YF-7200APP Volt Amp Clamp Meter?
- ?This clamp meter can remotely monitor on your phone.Easily test AC/DC voltage, AC/DC current,capacitance,temperature(?/?),diode, continuity, and resistance.
- ?Feature with relative value 6000 counts auto-ranging function allows you to get quick and accurate results.
- ?Come with backlight+flashlight,the easy-to-read LCD display and brightness gives you clear measurements.
- ?Data hold;Displaying Max/Min/AVG data for your recording.
- ?Jaw Caliber Size 26mm, easy to use while on work.
- ?It will not auto power off to support continuous measuring, data logging and then export the data in file or chart in your smartphone or tablet.
- ?Free APP available for download on App Store,Google Play, Life-time support.
Package Included:
- 1 * YF-7200-APP Clamp Meter
- 1 * Test Lead
- 1 * Thermocouple
- 2 * 1.5V(AAA) Battery
- 1 * Instruction Manual
