Description:
The push button switch station consists of three switches, one is a 2NO 2NC momentary red push button switch, one is a 2NO 2NC momentary yellow switch and one is a signal light.
Can be widely used to control the electromagnetic starter, contactor, relay and other automatic control electric circuits.
Comes with quick connect terminals to allow for fast connections.
Specification:
Material: PC
Action Type: Momentary
Contact Type: 2NO 2NC
Button Color: Red, Yellow
Red Button: Signal Light
Light Working Voltage: AC/DC 24V
Ith: 10A; Ui: 600V
Screw Hole Dia: 4mm / 0.16"
Hole Distance(center to center): 125 x 40mm/ 4.92" x 1.57" (L*W)
Total Size (Approx.): 138 x 72 x 80m / 5.43 x 2.83 x 3.15" (L*W*T)
Package Content:
1 x Push Button Switch Station, 1 x PG13.5 Cable Gland
