Product Features:
Built-in test point.
No need for tools.
Plug and play quick connecting.
Maintenance-free connection.
Low installed cost and safe operation.
Different wire sizes and types can be combined in one connector.
Corrosion resistance, high-temperature resistance and aging resistance.
Reusable conductor compact wire connector.
Product Specification:
Including 4pcs left Lever-Nut,4pcs right Lever-Nut and 28pcs Lever-Nut for DIY splicing.Use thick 99.99% content copper, Special surface plating to prevent oxidation and with good conductivity, low resistivity
Wire Cross section: 0.2~4mm²/28~12AWG (solid), 0.2~4mm²/28 ~12AWG(stranded),0.2~2.5mm²/28~14AWG (flexible)
Rated Voltage: 250V
Rated Current: 32A
Max Operating Temperature: 95?
Spring: Nickel Chromium Alloy Steel
Dimension: 31.5(L)* 8.0 (W)* 13.5(H)mm
How to Use?
1.Open the housing of wire to 0.39inch(10mm).
2.Push the orange lever to 90° and insert the wire lead.
3.Press the lever to close the clamp.
4.Check the test hole whether it is connected correctly.
UOHGDPY 36pcs Wire Connectors,Compact Wire Splicing Connector, 1 Conductor Compact Wire Connectors Splicing Connectors for Circuit Inline 28-12 AWG
Was:
$79.88
Now:
$39.94
- SKU:
- ZDF92911
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
