Todiys New 100Pcs for 2N7002 60V 115mA SOT-23 N-Channel Mosfet Transistor 7002

Compatible P/N: 7002 2N7002 Description: Condition: 100% Brand New And High Quality Material: Electrical Components Color: See Pictures Encapsulation: SOT-23 Maximum Diode Forward Voltage: 1.5V Configuration: Single Channel Type: N Number of Elements per Chip: 1 Maximum Drain Source Voltage: 60V Maximum Gate Source Voltage: ±20V Maximum Gate Threshold Voltage: 2.5V Maximum Continuous Drain Current: 115mA Maximum Gate Source Leakage Current: 100nA Maximum IDSS: 1uA Maximum Drain Source Resistance (mOhm): 7500@10V Typical Input Capacitance @ Vds (pF): 20@25V Minimum Gate Threshold Voltage: 1V Typical Output Capacitance (pF): 11 Maximum Power Dissipation: 200mW Operating Junction Temperature: -55 °C to 150 °C Minimum Operating Temperature: -55 °C Maximum Operating Temperature: 150°C Size: 2.8mm x 2.6mm x 1mm Quantity: 100 Pcs The 2N7002 from ON Semiconductor is an N-channel enhancement mode field effect transistor suited for applications involving low voltage and low current, such as small servo motor control, power MOSFET gate drivers and other switching applications. The 2N7002 features a high-density cell design, voltage-controlled small signal switch, high saturation current capability and rugged construction to ensure longevity. NOTE: Kindly compare your original item with the photos provided for the listing to make sure that you are purchasing the correct part. we don't provide technical assistance please make sure you are familiar with the product before purchasing. apologize in advance.
