Rapink Patch Panel 48 Port Cat6 10G Support, Network Patch Panel UTP 19-Inch, Wallmount or Rackmount 1U Ethernet Patch Panel Punch Down Block for Cat6, Cat5e, Cat5 Cabling

Patch Panel Cat6 Wall Mount Support Stable Connectivity and Fantastic Speed Performance up to 10Gbps. The Rapink ethernet patch panel support excellent performance transmission up to10-Gigabit, compatiable with the TIA/EIA 568-C.2 standard and cat6, cat5e, cat5e UTP cabling system. Standard 19-inch 2u patch panel suitable for Rackmount, Wallmount, or cabinets. All 8P8C of network network rack patch panel are golden plated to support better network connection up to 10G speed Ethernet network. 48 port atch cat 6 wall mount made of thick steel frame. Assembly 48 Cat6 Patch Panel with Punch Down Tool in Right Way. Network patch panel cat 6 is extremely easy and straight forward to install and use. 1. Cut off Cable sheath 2.5-3 cm. 2. Depatch each corlor wire and put into IDC hole according to 568B color labling on patch panel ethernet. 3. Punching down all wires into the hold of IDC connection with a punch down tool. 4. Tie up cables with plastic cable ties included to make them stable connectivity. This step is important. 5. Screw the 2u patch panel bracket on to racks with mounting bolts and nuts included. Important: With zip ties, it can effectively reduce the deformation of the ethernet cable, improve the working stability of the network connection port, and avoid the occurrence of network failures caused by the loosening and deformation of the cable. Clear 568B Labling on patch panels cat6 for Quick Reference of IDC Termination. 1. The punch down block allows to use both 568A and 568B standard with the punch down tool. 2. There is no problem punching down the solid Cat 6 lan cable 23AWG with solid connection. 3. Modular patch panel 48 port is economic in cost, great in value. 4. Ethernet patch bay segmented out based on portions of the panel. Therefore, if one port goes broken, you do have to take out an entire section to replace or repair. Nearby 5 other ports can still be used with good connectivity.
