NTE Electronics NTE1900 NTE Electronics NTE1900 3–Terminal Adjustable Positive Voltage Regulator Integrated Circuit TO92 Type Package 12V to 37V 100 mAmps

The NTE1900 is an adjustable 3–terminal positive voltage regulator in a TO92 type package capable of supplying in excess of 100mA over a 1.2V to 37V output range. This device is exceptionally easy to use and both line and load regulation are better than standard fixed regulators. In addition to higher performance than fixed regulators, the NTE1900 offers full overload protection available only in IC's. Included on the chip are current limit, thermal overload protection, and safe area protection. All overload protection circuitry remains fully functional even if the adjustment terminal is disconnected. Normally, no capacitors are needed unless the device is situated far from the input filter capacitors in which case an input bypass is needed. An optional output capacitor can be added to improve transient response. The adjustment terminal can be bypassed to achieve very high ripple rejection ratios which are difficult to achieve with standard 3–terminal regulators. Besides replacing fixed regulators, the NTE1900 is useful in a wide variety of other applications. Since the regulator is "floating" and sees only the input–to–output differential voltage, supplies of several hundred volts can be regulated as long as the maximum input to output differential is not exceeded. Also, it makes an especially simple adjustable switching regulator, a programmable output regulator, or by connecting a fixed resistor between the adjustment and output, the NTE1900 can be used as a precision current regulator. Supplies with electronic shutdown can be achieved by clamping the adjustment terminal to GND which programs the output to 1.2V where most loads draw little current.
