Neoteck TRMS 9999 Counts EBTN Digital Multimeter, 3-Line Display with Analog Bargraph VFC AC DC Amp Volt Ohm Capacitance Temperature Live Wire NCV Tester

Overview This instrument is a 9999-counter, hand-held digital multimeter with true virtual value and manual/automatic integration. It has a large, double, invert digital LCD display with simulation bars and illumination lights which are easy for users to read. It has the functions of alarm for fuse tube fused, wrong insertion of measurement probe It is designed and manufactured according to the safety requirement for electronic measuring instruments and handheld digital multimeters specified in the international electrical safety standard IEC-61010. It meets the requirements of IEC61010's 600V CAT IV, 1000V CAT. III

Specifications: Display: invert digital LCD display, 9999 counts Measurement mode: Double-integral style A/D transform DC Voltage Range and Accuracy: 999.9mV/9.999V/99.99V ±(0.5%+3); 999.9V ±(0.5%+3) AC Voltage Range and Accuracy: 0.999V/9.999V/99.99V ±(0.8%+3); 999.9V ±(1.%+5) DC Current Range and Accuracy: 99.9?A/99.99mA/600.0mA ±(0.8%+3); 10A ±(1.2%+3) AC Current Range and Accuracy: 99.99mA/600.0mA ±(1.0%+3); 10A ±(1.5%+3) Resistance Range and Accuracy: 999.9?/9.999k?/99.99k?/999.9k?/9.999M? ±(0.8%+3); 99.99M? ±(1.2%+5) Capacitance Range and Accuracy: 9.999nF ±(4.0%+30) 99.99nF/999.9nF/9.999?F/99.99?F/999.9?F/9.999mF ±(4.0%+3) 99.99mF ±(5.0%+3) Frequency Range and Accuracy: 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz ±(1.0%+3) Temperature Range and Accuracy: -20?-1000?/-4?-1832? ±(1.0%+3) Diode test: (0.15V- 3V) AC Voltage Bandwidth: 40Hz - 1kHz

Features NCV: alarm beep sounds and LED blink if detect AC voltage Continuity: alarm beep sounds if resistance less than 30? True RMS Continuity Data hold Flashlight Over load protection Low Battery Indication Auto Power Off Short-circuit protection

Package: 1x Multimeter 1x Test Leads (pairs) 1 x K-Type Temperature Probe 2 x 1.5V AA Battery 1x User's Manual
