Description:
- ?LCD Display?: DC Buck Boost Converter LCD can display input and output voltage, temperature, output current, output power, output capacity, output time
- ?Numerical Control Adjustment?: Numerical control adjustment, accurate and fast, can step up or down, output voltage 0.6-36V can be adjusted arbitrarily, limit Current 0 to5A can be adjusted freely
- ?Multiple Protections?: Adjustable Voltage Regulator with input anti connection protection, connection will not out; output anti backflow, no need to add anti backflow diodes when charging the battery; has a variety of software protection mechanisms, and the protection threshold is adjustable. When the working parameters of the module exceed the protection threshold, the output is automatically turned off.
- ?Better Heat Dissipation Effect?: Thicker heat sink, two ways ventilation, better heat dissipation effect; intelligent temperature control fan, automatic start and stop. When the temperature is greater than 50 celsius degrees or the current is greater than 1A, the fan start automatically.
- ?Other Functions?: The module can be set to be turned on/off by default; the output is small and has n type filtering.
Specification:
- Input voltage: 6-36V
- Output current: 5A (Max)
- Output voltage: 0.6-36V
- Output power: 80W
- Voltage display resolution: 0.01V
- Current display resolution: 0.001A
- Conversion efficiency: about 88%
- Working : 120KHZ
- Material: PP
Size Chart:
7.8cmx6.1cmx4.2cm/3.07inchx2.40inchx1.65inch
Package Includes:
1 Piece DC Buck Boost Converter
Note:
Please allow slightly errors due to manual measurement and different monitors.
