Description:
This 12V 10A relay has large control power and the control performance is stable. Learning button design, one switch can be equipped with multiple remote control, or a remote control with multiple switches. Adopt high quality chip, and double-sided PCB circuit board, which make the relay more durable and compatible. The wireless signal program learning function makes the relay has strong ability of anti-interference
Features:
Perfect relay for your lost or damaged one.
Momentary, Self-locking, Interlock, 3 Commands.
Remote distance range is up to 200-500 meter.
One switch can be equipped with multiple remote control, or a remote control with multiple switches.
This relay is stable, durable and compatible.
Specification:
Type: 12 channel remote control switch
Output current: 20A
Static working current: ?6mA
Output voltage: AC 125V / DC 14V
Working voltage: 12V
Battery type: 1 x 23A/12V battery(not included)
Working frequency: 315 433MH
Remote control distance: Approx. 200-500M
Operating temperature: 40°C ~ +80°C
Receive Sensitivity: ?105dBm
Working mode: Momentary, Self-locking, Interlock
Relay size: Approx. 10 x 8 x 2.5cm / 3.93 x 3.14 x 0.98inch
Remote size: Approx. 12 x 5 x 1.5cm / 4.72 x 1.96 x 0.59inch
Weight: 243g
Working mode:
Momentary: Press every button on the switch, and the corresponding relay is connected. Release the switch, the corresponding relay is closed. You can only connect a relay at a time.
Interlock: Press every button on the switch, and the corresponding relay is connected. And then press the other button on the switch, the corresponding relay is connected. The other relay is closed. You can only connect a relay at a time.
Self-locking: The same button control a relay. Press once means opening, press again means closing. Two independent control.
Working mode switching & Switch pair instructions:
Momentary: Learn from
Maxmartt DC 12V Relay 12 Channel Wireless RF Remote Control Switch Transmitter and Receiver
Was:
$92.24
Now:
$46.12
- SKU:
- Z469221
- UPC:
- 738665073847
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
