ITEM ID:AN_GSM_046_MIMO
Cellular Antenna 4G LTE MIMO antenna 4G 3G and GSM screw mount cirucular shape 700-2700MHz SMA male 4G Main and AUX
4G LTE Antenna MAIN
Frequency:698~960MHz/1710~2690MHz
Polarization: Linear
Gain: 2.5dBic?Zenith?
V.S.W.R: <3.0
Impedance: 50Ohms
4G LTE Antenna AUX
Frequency:698~960MHz/1710~2690MHz
Polarization: Linear
Gain: 2.0dBic?Zenith?
V.S.W.R: <3.0
Impedance: 50Ohms
Mechanical
Cable:RG174
Connector: SMA male
Radome Material?ABS
Mounting Method : Screw
Environmental
Operating Temperature?-40?~+85?
Relative Humidity : Up to 95%
Ingress Protection?IP67(exclude cable outlet)
Vibration:10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly:ROHS Compliant
?Two Leads 4G/3G/GSM Cellular FREQUENCY?:4G Main 700-2690MHz 4G AUX 700-2690MHz Ideal for signal reception of GSM 2G/3G/4G LTE Cellular MIMO wireless devices.
?PREMIUM QUALITY ANTENNA?: Our Omni-Directional Screw Mount Antenna is made from durable material - reinforced plastic, copper wire. It will be a professional, durable accessory!
?Multiple applications?: For industrial, commercial and Internet Of Things (IOT) applications such as: Hotspots, Kiosks, Vending, Point-of-Sale (POS), Machine-to-Machine (M2M), Video Surveillance (Cameras, DVRs, NVRs), Vehicles, SCADA, Telemetry, PLCs, RTUs, Digital Signage etc.
?IP67 WATERPROOF?: This antenna is completely waterproof (IP67) . Ideal for use outdoors, in vending machines, meter housings, equipment sheds, or other locations requiring a low-profile vandal resistant external antenna.
?100% Satisfaction Guarantee?: We are committed to providing customers with the best product and services. If you have any question, please feel free to contact us and if the good is with any quality issue, we're happy to offer you a new one!
