LINKOMM UL Listed RJ45 Cat6 12 Port UTP Unshielded Patch Panel with 89D Mounting Bracket Vertical Mini Patch Panel

LINKOMM RJ45 Cat. 6 12-Port UTP Unshielded Patch Panel with 89D Mounting Bracket LINKOMM 10" RJ45 Cat6 Mini Patch Panel provides the fast data transfer performance certified with TIA/EIA 568C.2. It supports 10G BASE-T Ethernet. The IDC terminations support either 110 or Krone punch-down tool. Nice and neat color-coded labeling identifies T568A and T568B Wiring. The flush front RJ45 modular jack patch panel improves the professional structured cabling for small office and home office. Material - Front Panel: SPCC, 1.5mm thickness with Black (RAL 9005) color painted - RJ45 jack housing: ABS+PC, UL 94V-0 - RJ45 contact bracket: PC, UL94V-2 - RJ45 jack contact material: phosphor bronze with Nickel plated - RJ45 jack contact finish: 50 micro-inch gold plated on plug contact area - IDC housing: PC and Glass Fiber, UL94V-0 - IDC Terminal: phosphor bronze with tin plated - Panel bracket: ABS, UL 94V-0 - PCB: FR4, UL 94V-0 Performance - T568A & T568B wiring - Insertion force: 20N max. - Retention strength: 7.7kg between jack and plug - Operating temperature: -10? to 60? (ISO/IEC 11801, ANSI/TIA 568 C.2) - Jack Life (mating cycles): 750 cycles min. (ISO/IEC 11801, IEC 60603-7-4) - IDC Life (mating cycles): suitable for 22-26 AWG stranded and solid wire, compatible with 110 and Krone punch-down tool - The transmission performance is in compliance with the ANSI/TIA 568 C.2 standard Package Contents - 1 X 12-Port Patch Panel - 1 X 89D mounting bracket - 2 X mounting screws
