Description:
It is a 3.5 inch TFT LCD display module.Its driver chip is ILI9486.
Feature:
1>.TFT LCD display.
2>.High Definition.
3>.RGB display.
Parameter:
1>.Product Name: 3.5 inch TFT LCD display module
2>.Work Voltage: 3.3V
3>.Display Size: 3.5inch
4>.Resolution: 320*480
5>.Driver Chip: ILI9486
6>.Number of Pins: 24
7>.Pixel Size: 0.153*0.153
8>.Operating Temperature: -20?~70?
9>.Operating Humidity: 5%~95%RH
10>.Model Size: 97*57.5*12mm
Common Pin:
1>.GND:Power negative
2>.VCC:Input power supply positive 2.8V~3.3V
3>.CS:Display Chip Select
4>.RS:Data or register select
5>.WR:Parallel port control pin
6>.SDA:Serial data input signal
7>.RES:Display reset terminal,low level reset
8>.D1~D15:16 bits date bus
9>.BLK:Blacklight Control(Low level turns off the backlight,brightness can be adjusted by PWM wave to control the backlight switching time)
Package:
1pcs 3.5 inch TFT LCD Display Module
LCD Display Module 3.5inch 320x480 RGB TFT Display Module SPI TFT LCD Screen ILI9486 Driver 320480 3.3V IPS LCD
Was:
$71.88
Now:
$35.94
- SKU:
- K29487
- UPC:
- 779288309777
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
