KQ130F Power Line Carrier Module Distance 220VAC Power Line Transceiver Powerline Carrier Module for Arduino Long Distance Data Communication

Specifications: Working Frequency: 120~135KHZ Connector Baud Rate: 9600bps Actual Baud Rate: 100bps One Frame Continuous Send Max. Length:  ?252 bytes (user defines  from 1 to 252, module will not send redundant data) Receive Sensitivity: ?1mV Out-of-band Rejection Ability: ?60dB Band Width: ?10 KHZ Insulation Resistance: 500V?500M? Power Supply: DC +5V(receiving: ?11mA; sending: ?230mA) Frequency Insulation Withstand Voltage: AC to GND 3000V (1min test no breakdown, nor current leak) Operating Temperature: -25?~70? Operating Humidity: ?90% Size: 5.3*4.5*1cm/2.08*1.77*0.39in Weight: 30g(approx.) Wiring: 1P---AC: 220V live wire (or neutral wire) 2P---AC: 220V neutral wire (or live wire) 3P---+5V: +5V sending power supply(210mA), if only receiving data, can be disconnected to reducing power consumption 4P---GND: Digital circuit ground 5P---+5V: +5V working power supply 11mA 6P---RX: TTL level, carrier data input, connect to TXD of SCM 7P---TX: TTL level, carrier data output, connect to RXD of SCM 8P---MODE: Mode selection, connect to 5V as high level or disconnect, connect to ground as low level 9P---NC/RST: Reset pin(low level effective), for frequent switching modes. No connection if do not use this function. Package Includes: 1 x Power-line Carrier Module
