KEYESTUDIO 4DOF Robot Arm Kit for Arduino Project, Electronic Coding Robotics for Kids Age 12+, Joystick Controlled, Bluetooth Controlled, PS2 Controlled

Overview With this keyestudio robotic arm kit, you are able to DIY your own controllable mechanical arm using microcontroller. It uses UNO R3 and 2 Joystick modules to control the angle degree of 4 servos. When DIY this 4DOF robot arm kit, you could get everything needed for arm installation and debugging. The parameters of keyestudio TB6612FNG motor/servo drive expansion board are as follows: VIN voltage: VIN = DC 7-15V VIN current: 5A Two-way 5V output: 5V/3A TB6612FNG: VIN input DC 7-15V; average drive current 1.2A; peak current 3.2A PS2 interface: compatible with Sony PS2 receiver, can be plugged directly into the expansion board. Dimensions: 73*53.34mm Package contains? UNO R3 Main Board x 1 TB6612FNG motor/servo drive shield x 1 MeArm T=3MM Black Acrylic panels x 1 MeArm T=3MM Black Acrylic handle x 1 MeArm Black ABS Cylindrical holder Diameter 42mm x 1 Black 180° Servo x 4 Keyestudio Bluetooth Module-(HC-06) x 1 Keyestudio Joystick Module x 2 3D PS2 Joystick cap x 2 Yellow-black handle 3*40MM Phillips Screwdriver x 1 Galvanized M2+M3 2mm thin double-headed small wrench x 1 M3*6MM round-head cross screw x 12 M3*10MM round-head cross screw x 22 M3*16MM round-head screw x 2 M3*16MM flat-head screw x 2 M3*12MM round-head cross screw x 12 M3*30+5MM copper pillar x 4 M3*6mm+6mm copper pillarx10 M3 Stainless steel Hex Nut x 22 M3 hexagon Lock Nut x 24 M1.2x5MM Phillips tapping screwx8 M2x5MM Phillips tapping screwx10 M3 304 Stainless steel flat washer 3*7*0.5MMx10 M2x8MM Phillips tapping screw xx2 Male to female 10CM jumper wire x 4 female to female 50CM jumper wire x 10 Black 3*100MM cable ties x 1
