The EV18 headlight series is manufactured as another major led headlight and anti fog bulb style, which has 200% brighter than halogen bulbs. H1 led headlight used by a special flat style convention design of heat sink fitted with the fan. Design double heat sink and air fan will remain our product in high performance heat dissipation. This series provides high-end lighting, which is one of the latest technology on the market, and allows us to create a network of LED bulbs which is close to similarity in bringing the bulbs together. halogen and allows us to replace the original bulbs directly.
Parameter characteristic
?2 h1 headlight bulbs included.
?Non-adjustable mounting collar
?Single beam per h1 bulb
?Color temperature: 6000K
?Bright lumen per bulb: 3,000
?Effective lumen per bulb: 2,800
?Lux max over 3 meters: 5,000
?Lux max over 25 feet: depends on vehicles
?Amp Draw: 2.1 Amps on 14 VDC
Input voltage:
1. Input bulb 9-36V DC configuration (DRL compatible), but for orders we can make 12-24V DC bulbs.
2. Heat sink temperature:
30 Minutes tested: 135 Degrees to 207 Degrees.
3.Lifespan: LED Chip Rated over 50,000 hours
4. Guarantee: 2 years
Lighthouse dimension:
A: Bulb length (Base of the collar to the tip of the bulb): 80mm / 3.1inch
B: Diameter of bulb tip: 30mm
D: Installation depth of the heat sink (clamp to the base of the heat sink): 23mm
C: Radiator width: 35mm
Cord length: 260mm
Kairiyard H1 LED Headlight Bulbs 6000K HI Beam 55W 8000 Lumens Fog Lamp Extremely Bright DOB Chips Kit 2 lamps 360 Rotation Bi-Xenon All in One Conversion 2 Years Warranty
Was:
$77.88
Now:
$38.94
- SKU:
- O215209
- UPC:
- 729257343257
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
