Jienk DC 24V Control 4 SPDT 16Amp Pluggable Power Relay, Compatible with PNP NPN C45 DIN Rail Mount 4 Channels 1NO+ 1NC Relay Module, G2R-1-E

Applicable to PLC, Arduino, DSP, ARM, ARM, MSP430, TTL logic microprocessor systems and time relays etc., amplifying the control current of outputs, to protect key control systems not being destroyed. Technical Specifications: Input Operation Voltage: DC 24V Relay Mounting: PCB Pluggable Switching Voltage: 30VDC/250VAC Contact Rating(Current): 16A Coil Current: 21.8mA Coil power: 0.53W each Contact type: 1 normally open, 1 normally close Max frequency: 18000 times/h Coil resistence: 50m? Release time(at normal voltage): ?5ms Input/Output connections: Screw terminal block Wire range: 0.2 to 2.5mm²(24 AWG to 14 AWG) Stripping length: 6 to 7mm(0.24 to 0.28 inch) DIN rail mountable: 15/32/35mm NPN PNP Compatible Package includes: 1 x 4 Channel DC 24V Rail Mount Relay Interface Module
