Intermatic CD1-024R Compressor Defender Protects Central Air Conditioner / Heat Pump Compressors and Circuit Boards

Power disturbances damage air conditioner compressors without warning. Let the Compressor Defender by Intermatic take the hit so air conditioners are never interrupted. The all-in-one Compressor Defender device protects compressors and circuit boards in residential and light commercial applications from brownouts, surges and short cycles. The protective device can be installed inside a condensing unit or on an outdoor compressor. LED indicators provide real-time status updates for quick and easy troubleshooting. Compliant with AHRI Standard 110-1012 Range B2 for voltage drop protection. Specifications: 120-240 VAC Single Phase 60 Hz | Normally Closed Relay 24 VAC | Type 2 SPD | Control Output Current Rating: 2A @ 24 VAC, isolated N.C. contact | Voltage Protection Rating: L-N/G: 700, L-L: 1200 | Nominal Discharge Rating: In (10 kA) |Max Continuous Over-Voltage (MCOV): L-N/G: 150V, L-L: 300V | Short Circuit Current Rating: 20kA | Under-Voltage Response Time: 3 line cycles |Operating Temp: -40°F to 158°F (-40°C to 70°C).
