Package Included:
4 x Capacitive Soil Moisture Sensor
1 x 4 Channel 5V Relay Module
4 x Mini Water Pump
1 x 5M Vinyl Tubing
Specification:
Capacitive Soil Moisture Sensor:
Pin: Analog signal output, GND, VCC
Operating voltage: 3.3- 5.5 VDC
Output voltage: 0-3 VDC
Interface: PH2.54-3P
Size: 98 x 23mm (LxW)
5v 4 Channel Relay Module:
Equipped with high-current relay, AC250V 10A, DC30V 10A
5V 4-Channel Relay interface board, and each one needs 50-60mA Driver Current
Mini Water Pump:
Rated voltage: DC3V or 4.5V
No load of water discharge capacity: 100L / H
Load rated current: 0.18A
Use: diving type
Voltage range (V): DC2.5-6v
Vinyl Tubing:
-Material: PVC
-I.D. Size: 6mm
-O.D. Size: 8mm
-Length: 5m, the length can be cut by yourself
Gikfun Automatic Plant Watering System Self Watering Device with Soil Moisture Sensor for Garden Patio Lawn DIY Kit for Arduino EK8476
