"Your 100% Satisfaction is our Highest Priority", we will try our best to serve customers well
Specification:
*Voltage: DC 12V/24V
*Self-consuming: 12MA
*Rated Charge Current: 30A
*Rated Load Current: 30A
*Over charge Protection: 14.4V/28.8V
*Over charge Floating charge: 13.7V/27.4V
*Charge recover voltage: 12.6V/25.2V
*Over discharge Protection: 10.7V/21.4V
*Over discharge Recover: 12.6V/25.2V
*USB output: 5V/2A
*Operating temperature: -20?-+55?
*Size:187 * 90 * 47mm / 7.3 * 3.5 * 1.85inch
Note:
1.Make sure your battery has enough voltage for the controller to recognize the battery before first installation.
2. The regulator is only suitable for lead acid batteries: FLD, SLD, GEL, not for nickel hydride, lithium, ions, or other batteries. Let the children keeps far away from the storage battery and the controller.
Caution:
1. Controller should connect the battery first, and then connect the solar panel,and finally the load! The disassembly sequence is contrary to the wiring order!
2. Please keep it in cool and well ventilated place to maintain good heat dissipation,the temperature outside might go up to 60-75C which will lead to the blank of the LCD screen
Package Includes:
1 x Solar Charge Controller, 1 x User Manuall Warranty: 18-month product guarantee from Giaride
