Force Sensitive Resistor Thin Film Pressure Sensor MD30-60 0~30KG Diameter 30mm Resistance-Type Thin Film Pressure Sensor Force Sensing Resistor

Features: The flexible sensor has the characteristics of flexible ultra-thin, and extreme speed response, etc.  Waterproof and pressure sensitive dual function This pressure sensor has the characteristic of high stability, and long service life Highly sensitive flexible nanometer materials can realize highly sensitive detection of pressure. Application: smart home, automotive electronics, new energy When sensor detects outside pressure, the resistance of sensor will change. Pressure signal can be converted into a corresponding electrical signal output using simple circuit. Specification: Model: MD30-60 Length: 60 mm/2.4in Width: 5.8 mm/0.2in Range: 0 ~ 30 kg Thickness:less than 0.60mm Response point: less than 200g Test voltage: typical dc3.3v Durability: more than 1 million times Response time: less than 10ms Recovery time: less than 15ms Working temperature:- 20?~ 60? EMI: no ESD: Not sensitive Initial resistance: more than 10m? Weight:1g Package list: 1 x Pressure Sensor
