About pin header color, it has blue or yellow, we send it by ramdon.
Description:
This board is suitable for firmware burning test of modules such as ESP8266 ESP-01S/01 ESP-07/07S ESP-12E/12F/12S/F
All IO ports have been exported and can be used as a minimum system development board or a small batch burning fixture.
The board supports firmware one-click download function and adds programming.
Mode indicator (blue light) and serial communication indicator (green light).
Notice:
The module supply voltage is 3.3V DC and the current is 500mA or more.
Wi-Fi module IO maximum output current is 12mA.
Wi-Fi module NRST pin is active low; EN enable pin is active high.
The Wi-Fi module enters the upgrade mode: GPIO0 is at a low level, then the module is reset and powered on; the Wi-Fi module enters the normal working mode: GPIO0 is at a high level, and the module is reset and powered.
The RXD of the Wi-Fi module is connected to the TXD of the external MCU, and the TXD of the Wi-Fi module is connected to the RXD of the external MCU.
Package Includes:
1 X ESP8266 Code Burner Firmware Downloader
"
ESP8266 Firmware Downloader Flash Download Tool Test Board Code Burner for ESP8266 ESP-01S01 ESP-0707S ESP-12E12F12SF
Was:
$71.88
Now:
$35.94
