Operation Guidance:
Power button :
Long press it to turn on or off the EMF Meter
Short Press it to enable or disable the sound?Mutation Function
The Mutation Function is for people who think the alarm sound is annoying or to use it on some place like library.
MG/UT button :
Long press at least 3 seconds to set safe value. When the alarm value is blinking press °C/°F button to increase value by 0.1. Press Mode button to decrease vallue by 0.1. Simply press
MG/UT button to confirm the alarm value. Press power button to escape process.
Short Press to do selection of Units, Milli Gauss or Micro Tesla.
Mode button :
Long Press to turn the backlight on and off
Short press to do Data Hold & Max Measurement Function Shift
Data Hold & Max Measurement Function -When we are measuring something, the numbers are going to change.
Hold function is to freeze the readings. If we press this button twice, it will register the Max Measurement we've got.
?/? button :
Long Press to turn on or off the function off timer-Manual/auto shut off shift
Short press to do temperature unit ?/? Shift
Manual/auto shut off Shift-The device will turn off automatically after 10 minutes and won't consume any batteries.
Specifications:
Material: ABS Plastic
Display: 4 digits LCD Display
Unit: mG (Electric Field); ?T (Magnetic Field)
Range: 0?2000mG; 0?200?T
Accuracy: ±5% (50?T to 200?T)?T at 50Hz or 60Hz
Resolution: 1mG, 0.1?T
Alarm Threshold: 4mG, 0.4?T(Adjustable)
Temperature: 0?50? / 32?122?
Test Bandwidth: 30Hz-300Hz
Number of Axis: Single Axis Inductive Head
Sampling Rate: 0.5 Seconds
Test Mode: Bimodule Synchronous Test
Over Range Indication: LCD Displays ""HI""
Power Supply: 3 * 1.5V AAA Battery (NOT Included)
"
