DP20V2A Programmable Control Step-Down Power Supply Module, 0-2.00A Constant Voltage Current Buck Power Converter with LCD Display

Description: The constant voltage and constant current programmable control power supply module is cabinet and delicate, and it puts the collection of analog integration and digital control functions in one. Its adjustable output voltage range is 0-20.0V, step by 0.1V. Its adjustable output current range is 0-2.00A, step by 0.01A. Boot voltages can be stored freely and the model has two groups of quick storage voltage. Compared with the traditional analog power supply, it is more convenient to quickly extract the voltage or current required. LCD display on the model has the function of digital voltmeter and ammeter. You can view the preset voltage, input voltage, output voltage, the preset current, output current, output power and LCD brightness. Specifications: Model: DP20V2A Material: ABS Size: Approx. 79 * 43 * 26 mm / 3.1 * 1.7 * 1 inch Output Voltage: 0-2.00A Output Power: Maximum 40W Ripple Frequency: About 330Khz Input Voltage Range: 4.5-23V Output Voltage Range: 0-20.00V Package Weight: About 76g Package List: 1 * Programmable Power Supply 1 * User Manual
