Specifications:
Model: ZQ14009
Shell color: silver
Product material: stainless steel and ABS
Input voltage: 5V 1A
Power input: 5VDC
Power consumption: 5W
Control mode: controlled by DMX512 console, transmitter (male) plugged into the dmx console, receiver (female) plugged into the stage light.
Control channel: DMX512
Working mode: the transmitter indicator flashes red, the receiver indicator flashes green, which is the state of signal transmission.
Power cord length: 92cm
System information
CPU: 32-bit ARM core
Wireless parameters
Communication distance: 500m Operating band:2.400-2.4835GHz,ISM,126 bands
Modulation mode:GFSK
Maximum transmitting power: 23dBm
Receiving sensitivity: -94dBm
DMX signal interface: RS485
Auto restart timer: Built-in WDT
Operating Environment
Working temperature: -40~85°C,5~95%RH humidity
Storage temperature: -65~150°C,5~95%RH humidity
Scope of application: stage lighting, large cultural performances, stadium lighting, temporary stage performances, city lighting systems, television stations, conference centers, professional theaters, theme parks, dance halls, bars and small cultural performances, etc.
Grouping operation instructions:
(Note: the need to use the grouping setting items, you must be in two transmitters at the same time to control their respective lamps, this time only need to set the grouping, if you has only one transmitter does not need to set anything, after the power supply plug and play)
1. Press the button to display the current ID settings, and then press the ID settings, each press the ID value plus 1.
2. working status: LED always on: no DMX or wireless signal; red LED flashing: transmitting; green LED flashing: receiving.
Packing List:
Wireless DMX512 Transmitter + Power adapter + User manual
DMX Wireless, ZonQoonz 1pcs 2.4G DMX 512 Male Transmitter Long Version for Stage PAR Party Light Sliver
Was:
$121.88
Now:
$60.94
- SKU:
- ZDU384235
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
