?100% full load burn-in test
?Universal AC input / full range
?It's good quality & high performance
?Input: AC110-265V 50/60Hz
?Out put: DC 5V
?Protections: overload/ over voltage/ short circuit
?Cooling by free air convection
(Not suggest for use in bathroom)
?Connection:
?L/N: AC power input
?GND: DC power output "-"
?V: DC power output "+"
?+V / ADJ: Adjust the output voltage
?Safety Compliance: CCC/ FCC / CE
?Working Temperature: 0~40?
?Storage Temperature: -20~60?
?Ambient Humidity: 0~95% Non-Condensation
?Compatible with 3528, 2835 ,3014, 5050, 5630 ,5730 Led strip lights
How to calculate Support max LED Strip Length
Assumption: Your LED Strip 60LEDs/m, and each LED 0.2W,
then calculate max LED Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 24W(this listing)÷12W/m=2m
So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=2m light
Feature
Type Size(mm)
5V 2A 10W 70*39*31
5V 5A 25W 85*58*32
5V 10A 50W 159*98*42
5V 20A 100W 198*98*42
5V 30A 150W 198*98*42
5V 40A 200W 199*110*50
5V 60A 300W 215*115*50
You'll Receive
1Pcs Switch Power Supply Adapter for LED Strip
