Package include:
1x Relay Receiver board (include shell)
2x Transmitters (contain battery)
1x Product manual
Parameter:
-Receiver Working voltage: AC 85V~250V
-Input/Output vlotage: 1~250V
-Quiescent Current: <5MA
-Max current: 10A
-RF frequency: 433MHz
-Working temperature: -30~+80
-Receiving Sensitivity: >97dbm
-Amount of storage remote controls: 20 pieces
-Support encoding: 1527 Leaning code
-RF Operating mode: ASK superheterodyne wireless reception
-Receiving range: Open space is more than 50 meters
-Pin: COM,NO,NC
- Operating mode: Momentary /Toggle/ Latched Mode
-Battery: 2x CR2016(contain)
Usage:
Momentary Mode:
1. Press and hold one button, relay 1 will turn on;
2. Release the button, this relay 1 will turn off.
Toggle Mode:
1. Press button A, relay 1 will turn on;
2. Press button A again, this relay 1 will turn off.
Latched mode:
1. Press button A, relay 1 will turn on;
2. Press button B, relay 2 will turn on, at the same time relay 1 will turn off.
Reset:
Press the learning button (on the Receiver) 8 times. succeed.
Note:
After deleted the data, all the remote controls cannot work any more.
Setup
1. Press the learning button (once for Momentary mode, twice for Toggle mode, triple for Latched mode). Wait for 3 seconds;
2. Press button A . Wait for 3 seconds.
3. Press button B . Succeed.
DieseRC AC 110V 120V 220V 240V Wireless Remote Control Switch 433Mhz RF 10A 2CH Relay Receiver with 2 Transmitters for Garage Door Electric Curtain Motor Light DIY Radio Control Switch
Was:
$85.88
Now:
$42.94
- SKU:
- ZD331239
- UPC:
- 750828380647
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
