Specification:
Color: Black
Wiring: Export three-wire system
Voltage range: 12V 24V 36V 48V
Supply voltage: 8V to 50VDC (module normal operating voltage range)
Standby current: 0.5ma (silent state)
Output power: High power, load current 5A, the pressure drop is negligible.
Power consumption: 0.6Wmax
Anti interference delay: about 0.6 second
Sensitivity: 5-10LX on 30-60LX off
Environment temperature: -40? ~ +70?
Related Humidity: 99% RH
Working Life: 6500 cycles
Detector waterproof grade: IP 66
Use of the environment, temperature: Can not be installed in a corrosive gas environment, minus 25 to 70 degrees.
Leads Length: 150mm
Product Size: (L) x (W) x(H) 40 x 15.6 x 20 mm / 1.57" x 0.61" x 0.79"(appr.)
