Canying Car Rear View Reverse Back Trunk Handle Camera Special for BMW E60 E61 E70 E71 E72 E82 E88 E84 E90 E91 E92 E93 X1 X5

Important: it is NOT LVDS to original screen.the camera can NOT fit factory moniter.It is RCA for after installed medias. It can be added with a Camera 12V DC Power Adapter Filter Rectifier to solve flickering problem if the screen flickers after installed Compare the car handle size with camera size.(length 4.33inch / width 1.57inch) Suggested models: for BMW E60 E61 - 5 series E90 E91 E92 E93 BMW 1 Series E84 - X1 (Very important:The car models are for reference only,please check the camera size and check your truck handle shape. it may fit more cars or can't fit some cars in the list.Contact us if any doubt.We have size picture but please allow 0.5-1 inch difference due to manual measurement.) Note! If some cars original is 3pin,need to modify.Remove original 3pin connect with our camera.(Our camera is 2pin of boot connector.) Technical parameters Images sensors CMOS: (PC7070) Power Supply: DC12V Current Consumption: 100mA(MAX) Power: 1.2W(MAX) Effective pixels: 648*488 Electronic shutter: 1/60(NTSC)1/SD(PAL) 1/10,000 second Minimum illumination: 0.5Lux S/N Ratio: ?48dB Resolution(TV Lines): 580 TV System: PAL/NTSC Lens Angle(Deg): 170° Video output: 1.0vp-p,75ohm IP rating: IP67/68 White Balance: Auto AGC: Auto BLC Auto The product is easy installation and assembly, but Note: 1.This product is a 12V voltage. 2.When installing the product,be sure to use the specified drill,screws,etc. to avoid damage to the camera function Unique Design:This backup camera is with Guide Line (Yes/No) Switcher. It is with Guide line as default. Remember to turn off the power before switching 1.If you need a backup camera with distance scale line,you just install it without any operation. 2.If you need a backup camera without distance scale line,please cut the white wire.
