Arducam-Mini-5MP-Plus(OV5642) is performance improved version compared to its predecessor Arducam-M-5MP.
Arducam mini not only offers the capability to add a camera interface which doesn't have in some low cost microcontrollers,
but also provides the capability to add multiple cameras to a single microcontroller.
It can not only capture decent 5MP JPEG images, but also can do 5MP full resolution RAW image capture, which makes it to
be the ideal solution for IoT and scientific image processing applications. Even more it can record short movie clips as well.
Feature:
5MP image sensor OV5642
M12/CS mount replaceable lens
I2C interface for the sensor configuration
SPI interface for camera commands and data stream
Support external hardware trigger input
All IO ports are 5V/3.3V tolerant
Well mated with standard Arduino boards
Provide open source code library for Arduino, ESP8266, Raspberry Pi, etc
Small form of factor
Key Specifications:
Power supply 3.3V~5V
Active array size: 2592x1944
SPI speed: Max 8MHz
Shutter: rolling shutter
Frame buffer: 8MByte
Pixel Size: 1.4µm x 1.4µm
Default M12 Lens: 55°
Resolution support:5MP, 1080p, 720p, VGA, QVGA
Format support: RAW, YUV, RGB, JPEG
Size: 34 x 24 mm
Weight: 20g
Temperature: -10°C?+55°C
Packing included:
1pcs Arducam Mini 5MP Plus OV5642 Camera Module
NOTE: Arduino UNO is not incldued
Contact us for datasheet download link.
Arducam Mini Module Camera Shield 5MP Plus OV5642 Camera Module for Arduino UNO Mega2560 Board
Was:
$129.88
Now:
$64.94
- SKU:
- GZ396232
- UPC:
- 714119484421
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
