Approach Sensor TL-Q5MC2 DC PNP 3-Wire Inductive Proximity Switch 5mm Detecting Distance Normally Closed Proximity Sensor Switch

Specification: Model: TL-Q5MC2 Detection distance: 5mm ± 10% Set distance: 0 - 4mm Delay distance: <10% Detection distance Standard object: Magnetic metal(Detection distance decreases for nonmagnetic metals) Detect object: Iron 18*18*1mm Response frequency: DC:0.5kHz AC:25Hz Power: DC12 - 24V(6-36V); AC110 - 220V(36 - 250V)50/60Hz Withstand voltage:  AC1000V 50/60Hz Effect of Voltage: ±15% Rated voltage,  Impulse (P-P) below 10% Consumption current: N.P: <13mA, D: <0.8mA, A:<1.7mA Control Output: N.P: <300mA, D:<200mA, A:<400mA Circuit protection: A: Surge protection  N.P.D: Surge protection, Reverse Connection Protection Temperature range: -25 -+60? Isolation Resistance: >50M? Material: ABS Storage and use temperature: -30 - +65?(No ice, no frost) Storage and use humidity: 35 - 95%RH Package list: 1 * Inductive Proximity Switch Note: The actual product color may deviate from the photo due to light. There may be a slight deviation in the measurement of product.
