ANTOP Technology:
An exclusive technology offered by ANTOP, the inline Smartpass Amplifier's all-in-one design, allows you an easier connection and more possibilities in different receiving ranges.
This filter blocks 3G and 4G signals from mobile phones, tablets, wireless networks or mobile phone transmitters to ensure a noise-free digital TV reception.
Tips:
1. AT-601W must be powered for function. It can be powered via USB cable by connecting to any USB-port supporting 5V output. A USB AC/DC power adapter is included in package.
2. Re-scan the channels after each switching of the Smartpass Amplifier.
3. Scan channels monthly to find all available channels including newly added or changed.
4. Do not place or hide the Smartpass Amplifier in/behind any metallic objects.
5. Keep the antenna away from any high power consumption devices to avoid interference.
Smartpass Amplifier Features
Power Supply: DC 5V/50mA
Color: White
Size:2.90x1.26x0.70in
TO TV: 3ft Extension Coaxial Cable Attached with F-male Connector
TO Antenna: 0.3ft Extension Coaxial Cable Attached with F-female Connector
Exclusive Technology: Smartpass Amplifier, Built in 4G LTE Filter
Smart Switch On: Long range reception
Smart Switch Off: Short range reception
What's in the box
AT-601WSmartpass Amplifier and Power Supply Kits
USB AC/DC Power Adapter
USB Cable
Instruction/User Manual
Technical Specification
1)Smartpass Amplifier
Frequency Range: 87.5-700MHz
Receiving Range: FM/VHF/UHF
Gain: 16dB Max
Output level:105dBuV Max
Impedance:75?
Noise figure:?2dB
Return Loss: >8
Power Supply: DC5V/50mA
2)USB AC/DC Power Adapter& USB Cable
Input: 100-240V~50-60Hz, 150mA
Output: DC 5V 200mA
USB Cable Length: 5ft
ANTOP Smartpass Amplifier Power Adapter and 5ft USB Cable Included (Black)
$13.99
- SKU:
- FF14429
- UPC:
- 750440826103
- Condition:
- New
- Availability:
- Free Shipping from the USA. Estimated 2-4 days delivery.
