ANMBEST 2PCS Dual USB2.0 Panel Mount Connector, 2 Ports O-Type Female to Female USB Pass Through Bulkhead Coupler Adapter with Weatherproof Dust Cap

A dual ports USB 2.0 panel mount connector is a type of connector designed for mounting on a panel or surface and provides two USB 2.0 ports. It allows for easy access to USB connectivity in applications where the ports need to be fixed in place, such as in industrial equipment, medical devices, or custom computer cases. Specifications: Waterproof rating: None (without waterproof cover), IP67 (with waterproof cover) Connection type: USB2.0 Transmission speed: 480Mbps Core: 4 Electrical parameters: Rated current: 1.5A Rated voltage: 50V Insulation resistance: ?500M? Dielectric strength: DC1000V Contact resistance: ?10m? Material: Shell: Zinc diecast (ZnAl4Cu1) Shell plating: nickel plating/black electrophoretic paint Contact material: Bronze (CuSn8) Contact pin gold plating: 7µm Au over Ni plating Waterproof rubber ring: silicone Environmental conditions: Working temperature: -40?120Celsius Storage temperature: -25?85Celsius Atmospheric pressure: 86?106kPa Relative humidity: ?90% RH Mechanical parameters: Insertion pressure: less than 10N Withdrawal pressure: less than 10N Service life: more than 1000 times Installation panel thickness: min 2.0mm-max 10mm Base shape: O type Installation hole size: 22.5mm NOTE: The shielded industrial panel mount bulkhead includes a water/dust cap, that with characters of fire safety, compression, anti-explosion and anti-deformation, meets IP67 Water Protection. It is not waterproof without water/dust cap. Package Included: 2x Dual port dual channel USB2.0 connector 2x Waterproof/Dust Cap Cover
