ANENG AN8009 Auto Ranging Digital Multimeters LED 9999 Count True RMS AC/DC Voltage HFE Electronic Meter Voltage Current Amp Resistance Diodes Continuity for Automotive

ANENG AN8009 is one of the first 9999 count, auto-range digital multimeter. This product is battery-powered with true-rms, LED display and backlight. Digital multimeter model can measure AC / DC voltage, DC Current, Resistance, Continuity, Diodes, Transistor hFE and so on. Portable, and easy to use. It can service well in fielf of maintenance of auto, electrical engineering and teachig lab, ect.

Specifications:
Brand Name: ANENG
Model Number: AN8009
Color: Orange
Operating Temperature: 0 - 40 ?
Operating Humidity: ?75%RH
Storage Condition: -20~60?
Storage Humidity: ?80%RH
DIY Supplies: Electrical
Operating Mode: Auto/Manual Ranging
Measuring Inductance Range: no
Measuring Temperature Range:  -20~1000 C/-4F-1832F
Measuring Capacitance Range: 9.99nF/99.99nF/999.9nF/9.99uF/99.99uF/999.9uF/9.999MF
Measuring Voltage Range: 999.9mV/9.999V/99.99V/999.9V
Measuring Current Range: 60mA/600mA/10A
Measuring Resistance Range: 99.99/999.9/9.999k/99.99k/999.9K/999.9M
Frequency: 99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz
Square Wave Output: 50Hz/100Hz/200Hz/300Hz/400Hz/500Hz/600Hz/700Hz/800Hz/ 900Hz/1000Hz
DC/AC Voltage(mV): 9.999mV/99.99mV
DC/AC Voltage(V): 999.9mV/9.999V/99.99V/750ACV(999.9DCV)
DC/AC Current (mA&A): 999.9mA/9.999A
DC/AC Current (uA): 99.99?A/999.9?A
Display Type: Digital Display
Diode Test: Yes
Continuity: Yes
Duty Cycle: 1%-99%
Sample Rate: 3 times per second
Power Supply: 2 x 1.5V AAA batteries(Not Included)
Quantity: 1pc
Size: Approx. 130 x 65 x 30mm / 5.12 x 2.56 x 1.18inch
Weight: 347g

Package Included:
1 x Multimeter
1 x Test lead+temperature sensor
1 x 16 in 1 Multifunctional Test Line
1 x Bag
1 x User Manual
