ACROBOTIC ESP8266 ESP01 WiFi Module Adapter for WS2812B Compatible with Arduino Raspberry Pi ESP01

The ESP-01 is a very popular module based on the ESP8266 chipset that lets you run and control your electronic projects over WiFi. Using an ESP-01 (or any other ESP8266 variant) can be a bit tricky, as some wiring is needed to both program and access its GPIO through the module's 2×4 pin header. This shield makes it easy to connect the ESP-01 to any WS2812B/NeoPixel product. Simply plug the ESP-01 into the shield's 2×4 header, and easily wire GPIO2 using a separate, built-in 3-pin PH2.0 connector. The shield also offers a 2-pin male header for supplying power to the ESP-01 through an LDO regulator. The power pins are also connected to the 3-pin PH2.0 connector. It works great with 3.7V lithium batteries. Features: Operating Voltage: 3.7~5.5V (Onboard 3.3V 350mA LDO Regulator) 2-pin 2.54mm pitch header for power 3-pin PH2.0 connector for accessing power and GPIO2 Built-in reset button Easiest way to connect an ESP-01 module to WS2812B/NeoPixel products We have written useful guides for getting you started with using this shield with the ESP-01 module: http://learn.acrobotic.com/tutorials
