ACROBOTIC 2-Channel Relay Board AC250V 10A DC30V 10A for Arduino Raspberry Pi ESP8266

This 2-channel relay interface board allows you to control different appliances and equipment that use high-current draws using low voltage outputs such as those used by microcontrollers like Arduino (ATmegas, ARMs) and ESP8266 development boards, or by SoCs like the ones on a Raspberry Pi or BeagleBone single-board computer. These modules are very straight-forward to use, you connect the pin header to power (5V and Ground) and to the digital I/O of your microcontroller or SoC. Then, you use the screw terminals to connect the HOT/LIVE wires of your appliance and its supply. The supply wire goes into the COMMON terminal (located in the middle of each 3-pin terminal), and the HOT/LIVE wire goes into either the NO or the NC terminal located besides each the COMMON terminal. Depending on the logic level on the microcontroller/SoC side, the COMMON terminal is connected to either the NO or the NC terminal and can be switched back and forth by firmware/program's logic. Please remember to always use proper precautions when working with high-current devices! Features: 5.0×4.5cm breakout PCB for 2 independent, high-current relay modules! Sturdy (1.6mm), blue PCB with a 4-pin header on one side (Vdd, Vss, IN1~2) and 2×3-pin screw terminals on the other (NO, COMMON and NC) We have written useful guides for getting you started with this 2-Channel relay board using your favorite microcontroller or SoC: ESP8266: http://learn.acrobotic.com/tutorials/
