Ableconn PEX UB108 USB 3 0 2 Port PCI Express PCIe Host Adapter Card NEC Renesas UPD720200 chipset

Add two SuperSpeed USB 3.0 Type-A ports with up to 5Gbps data rate to your system. Specification * Connector: - 2 x USB 3.0 Type-A female - 1 x 15-pin SATA power connector (optional connection) * Chipset: Renesas (NEC UPD720200) * Software: - No driver installation is required on Windows 10, Win8, Server 2012, Linux kernel 2.6.31 and later OS. The OS buit-in USB drivers support UASP. - The Renesas drivers are available for 32/64 bit Windows Windows 7/Vista/XP, and 64bit Server 2008 R2 * Data transfer rate: - USB 3.0 up to 5 Gbps * USB 3.0 PCI Express 2.0 x1 Lane Host Adapter * Supports PCIe 1.0 and PCIe 2.0 motherboard * Compliant with PCI Express Specification 2.0 * Compliant with Universal Serial Bus 3.0 Specification Rev. 1.0 * Compliant with Intel eXtensible Host Controller Interface (xHCI) Specification 1.0 * Compliant with USB Attached SCSI Protocol (UASP) Specification 1.0 * Support USB3.0, USB2.0 and USB1.1 devices * Provides USB 3.0 power to USB devices from Motherboard PCIe slot directly, or from PC power supply if on board 15Pin SATA power connector connected * Low Profile PCIe Form Factor board * Include both Low Profile and Regular Size PCIe brackets * Fully RoHS compliant. * Made in Taiwan Package Contents * Ableconn USB 3.0 2-Port PCIe Host Adapter Card * One (1) low profile PCIe bracket * Quick Installation Guide
