Specification * Connector: - 2 x eSATA (7 pin; Data) Female - PCI Express x1 Male * Chipset: MARVELL 88SE9128C0 * Software: - No driver installation is required on Windows 10/8/7/Vista, Server 2012/2008, Linux, Mac OS X 10.x and later. The AHCI drivers are natively built-in on most Operating Systems - Drivers are available for Windows XP * Data transfer rate: - Up to 6 Gbps * Number of Ports That Support Port Multiplier: 2 (can only use 1 PM at a time) * Number of Drives Supported Through Port Multiplier: 1 to 5 * 6Gbps eSATA III External 2 Ports PCIe Gen2 x1 lane host adapter * Hardware RAID controller to offload host CPU for max performance * Supports PCIe 1.0 and PCIe 2.0 motherboard * Compliant with 5Gbps PCI Express 2.0 * Fully compliant with Serial ATA specifications3.0 transfer rate of 6Gbps * Supports SATA I & SATA II & SATA III HDD, SSD, Optical Drive and Blu-Ray Drive * Supports Non-Raid, Hardware RAID 0, 1 for HDD & SSD * Supports Non-Raid mode for Optical Drive and Blu-Ray Drive * Supports ATA and ATAPI commands * Supports SATA Hotplug, and Native Command Queuing (NCQ) * Supports one (1) Port Multiplier with FIS-based or Command-based switching * LED Pin headers for LED activity indicators for each port * Low Profile PCIe form factor card on a regular size bracket with an additional Low Profile bracket included * BIOS on board supports Windows booting * Fully RoHS compliant. * Made in Taiwan
Package Contents * Ableconn 2-Port eSATA 6G PCI Express Host Adapter Card * One (1) low profile PCIe bracket * Quick Installation Guide
