Parameter:
Input voltage: 3.2V~46V (recommended for use within 40V)
Output voltage: 1.25V~35V
Output current: 3A (maximum)
Conversion efficiency: 92% (maximum)
Output ripple: <30mV
Switching frequency: 65KHz
Working temperature: -45 C ~ +85 C
Size: 43mm * 21mm * 14mm
Application:
1. Car power supply, power supply for your mobile phone, MP3, MP4, PSP and many other devices, very simple and convenient.
2. Power the electronic equipment. When the equipment needs 3-35V power supply and the corresponding voltage power supply is used, this module can conveniently adjust the voltage to the required voltage.
3. System working voltage test, this module can be used to debug the working voltage range of various voltage test systems.
Input voltage: 3.2V~46V (recommended for use within 40V)
Output voltage: 1.25V~35V
Output current: 3A (maximum)
Conversion efficiency: 92% (maximum)
Output ripple: <30mV
Switching frequency: 65KHz
Working temperature: -45 C ~ +85 C
Size: 43mm * 21mm * 14mm
Application:
1. Car power supply, power supply for your mobile phone, MP3, MP4, PSP and many other devices, very simple and convenient.
2. Power the electronic equipment. When the equipment needs 3-35V power supply and the corresponding voltage power supply is used, this module can conveniently adjust the voltage to the required voltage.
3. System working voltage test, this module can be used to debug the working voltage range of various voltage test systems.
