3 in 1 NGFF and mSATA SSD Adapter Card Electop M_2 NVME to PCIE M_2 SATA SSD to SATA III mSATA to SATA Converter Support 2280 2260 2242 2230 Host Controller Express Card

?M.2 NVME to PCI-e 16X ?M.2 SATA SSD to SATA III ?mSATA to SATA Product Specifications: ?SATA slot data transfer up to 6.0Gb/s ?Supports SATA-based B key and PCI-E 4X-based M key NGFF SSD ?Supports 2230, 2242, 2260 & 2280 size NGFF SSD ?Easy installation & no driver required ?No additional power required,plug and play,easy installation ?Supports any OS, like Windows, WinCE, Mac & Linux etc 1.Connects one B key & one M key NGFF SSD at the same time to PCI-E 16X motherboard. 2.PCI 3.0 (Back Compatible with PCIe 2.0,PCIe1.0) Express M.2 specification 1.0. 3.SATA 3.0 specification for B key(SATA based). 4.PCI-E 3.0 specification for M key(PCIE or AHCI based). 5.mSATA SSD card supported. 5.Compliant with 39Gbps PCI Express 3.0. 6.Four SSD card length Supported,2280 /2260 /2242/ 2230. Please Kindly Note: ? 7-pin SATA cable must be connected to motherboard if you want to read the M.2 SATA SSD (Key B) for data transfer, supply with sata cable in package. ? M key SSD there must be a 2.0 or higher PCI-E 16X socket. ? This adapter only support PCIe X16 slot. DO NOT support PCIe X1,X4, X8 slot. ? All of the 3 SSDs(M.2 PCIE-based SSD, M.2 SATA-based SSD and mSATA SSD) can work at the same time. This adapter card work under 12V+3.3V, and power supply can reach 3.3V x 8A at maximum. ?NVME M.2 to PCIE 3.0x4 (32Gbps), no need to use SATA cable to connect to the PC. ?When working with SATA M.2 to SATA III (6Gbps) and mSATA to SATA III (6Gbps), a SATA cable is required to connect the motherboard. ( 2 SATA cables have included already) ?When you insert or remove SSD ,please make sure that power is off. What You will Receive: 1*3 in1 M.2 to PCI Express Adapter Card(with fixed regular size Stainless steel bezel) 1*Small size Stainless steel bezel 2*SATA Cable 11*Screws and nuts
